Tutorial

How to Install and Configure Grafana

Grafana is one of the most famous open source tools for monitoring and get information from several data sources. Learn to install and set up Grafana on Ubuntu.

LHB Community

Warp Terminal

Grafana is one of the most famous open source tools for monitoring and get information from several data sources. It’s well known for its beautiful and clean dashboards, where it can be easily set and configured. It can provide awesome graphs and manage alerts to help the user to take the right actions.

Grafana supports an enormous number of databases. The main use of Grafana is displaying information by time series data, like CPU, memory and hard disk usage over time. But you are free to create all kind of hosts (devices to monitor) and grab everything that is measurable. You can monitor data centers, printers, routers, IoT devices and so on.

Another big advantage of this amazing software is that it is available for all operating systems, Linux, Mac and Windows. The community is vibrant and develops many plugins to improve the data visualization.

Grafana Dashboard Example
Grafana Dashboard Example

Requirements for Grafana

To run Grafana you will need to guarantee the minimum requirements, such as a supported operating system, database and browser.

Supported operating systems

  • Debian, Ubuntu, RPM-based distros (CentOS, Fedora, OpenSuse, RedHat)
  • macOS and Windows

Minimum hardware

  • Minimum recommended memory: 255 MB
  • Minimum recommended CPU: 1

If you intend to use a lot of databases and dashboards, a more powerful machine is recommended.

Supported Databases:

Grafana is flexible and supports a lot of databases.

Grafana Supported Databases
Grafana Supported Databases

Supported web browsers:

The official documentation recommends using the following browsers to view the Grafana dashboard:

  • Chrome/Chromium
  • Firefox
  • Safari
  • Microsoft Edge

You may use other options, since JavaScript is enable. But for precaution, use one of the list above.

Installing Grafana on Ubuntu or Debian

In this article, I will show you how to install Grafana on an Ubuntu or Debian-based system.

The easy way is to download the latest Grafana version in the form of .deb package. But this way, your Grafana install won’t get future updates and you’ll have to manually install the newer version.

This is why the better way is to add it to your repository list and then install the latest stable release. This way, your Grafana install gets regular updates.

In the terminal, add this command to use apt over https:

sudo apt-get install -y apt-transport-https

Now enable the software-properties-common package so that you can add additional repositories:

sudo apt-get install -y software-properties-common wget

Use wget to get the GPG key and add it to your system:

wget -q -O - https://packages.grafana.com/gpg.key | sudo apt-key add -

Rest is easy. Update the software repository cache:

sudo apt-get update

And then install Grafana:

sudo apt-get install grafana

Now that you have installed Grafana, let’s see how to set it up properly.

Configuring Grafana

Let’s start Grafana service:

sudo systemctl daemon-reload
sudo systemctl start grafana-server

You should also enable this service so that Grafana is started at each system boot:

sudo systemctl enable grafana-server.service

Grafana works like a web service, so you need to access it from a browser. Open your browser and go to http://localhost:3000/.

In the login page use the default username and password. Use the IP address of the machine if you are accessing Grafana on a different machine in your network. The 3000 is the default HTTP port. It’s possible to change it if you want.

  • username: admin
  • password: admin
Grafana Login
Grafana Login Page

It’s highly recommend to create a new user with a strong password. After that, you can disable or delete the default admin user for security purposes.

Setting up your first dashboard

Before starting to monitor anything, you need to include your database in the configuration menu.

Grafana Add Database
Grafana Add Database

After you have configured your data source you are ready to continue and design the dashboard.

To create graphs and indicators is easy, you have a lot of options and all of them are well documented on the Grafana website. You just have to explore it a bit.

Grafana Visualization
Grafana Visualization

Now it’s up to you to use your creative potential and construct beautiful dashboards.

Written by Marcelo Melo
