dd Command in Linux: 5 Real World Examples Explained

It has been suggested that the name is derivative of an older IBM Job Control Language function where dd stood for “Data Definition”. In Linux, the abbreviation stands for “Data Duplicator” or “Disk Dump” or a variety of other alliterations depending on your source.

It may have even earned the poignant nickname “data destroyer” which brings me to an important point. Please exercise caution when practicing the dd command.

This command is capable of doing some serious damage. Be sure to double check your syntax to avoid a costly mistake. You don’t want to be the person that confuses partition names and watches in agony as their root partition is destroyed and replaced with a blank file.

Getting to know the dd command

Here’s the syntax of the dd command:

dd if=<filename> of=<filename> [options]

There are a wide range of uses for this command, I’ll introduce some common approaches.

Physical Media / Partition Clones/Back-Ups

In the above syntax, ‘if’ and ‘of’ are for input file and output file, respectively. This is the core functionality of dd. It duplicates data from one source to another. You don’t need to use physical media with dd.

Text Manipulation

It is possible to use stdin (standard input) from your keyboard to collect input and point it to a file. It’s also possible to quickly convert case and a variety of other useful text editing tools are included in the man page.

I mentioned IBM earlier alluding to the long history of this program. One of the original functionalities of this command actually centered around converting EBCDIDC, an encoding schema created by IBM, to ASCII.

Filesystem Manipulation

You can also copy files with it, but the cp command is recommended over dd for this simple application. We have an article where you can read about the cp command.

Some Behavioral Notes

When copying with dd, you should also be aware that by default it will copy the complete information from a specified source.

Meaning that if you try to duplicate a partition or a disk, it will also copy free space.

So, for instance, if you’re cloning a hard drive with 4 TB, you will need a destination drive with at least 4 TB to prevent truncated files and errors. Remember also, if the disk has only 1 TB worth of data, dd will still copy the other 3 TB of space. That’s a bad move that will waste a lot of time and resources.

There are some constraints that we can add to dd and other measures we can take to change this behavior. There are actually an overwhelming amount of controls that can be used in conjunction with dd. I will try to address some of the ones that I think may benefit our readers most, but the goal of this article is to give a primer on dd, not document every possible function.

Attention! For practicing, use a Virtual Machine

I urge you to conceptualize your goal and carefully execute it to avoid corrupting or destroying important files. Obviously, we are not liable for the loss of your information. If you make a mistake. Don’t say we didn’t warn you.

I recommend practicing on a dummy virtual machine to familiarize yourself before attempting to alter any “real world” assets. This is because dd command has ability to change and thus damage your filesystem if you use it incorrectly.

For this tutorial, I decided to try something outside the Debian family and spun up a copy of Fedora 31 in VirtualBox.

5 Practical examples of the dd command

With the warnings and some contextual information out of the way, we are ready to move on to some applications for this simple but powerful command.

Example 1: Clone disks

Cloning one disk to another can be very easy with dd. For my example, I have two disks named ‘sda’ and ‘sdb’.

Remember that ‘sda’ will attempt to copy itself onto ‘sdb’ using the entire contents of the drive, not just the data.

You need to allocate enough space on your output file to accommodate for unused space on the sector. You can also choose to re-partition the drive to the exact size currently filled by data. I would recommend this method. It will decrease the amount of time it takes to perform the operation and create a more useful document.

When you’re ready to clone a disk, you can run fdisk to identify your disks, their partitions, and their capacity.

sudo fdisk -l

Running this command will list available drives and partitions and their respective sizes. This can be helpful for correctly identifying your target device.

Again, for our application we are using the names ‘sda’ and ‘sdb’ and we will assume they are the same size.

[linuxhandbook@fedora ~]$ sudo dd if=/dev/sda of=/dev/sdb
[[enter pw for sudo]]
dd: writing to 'dev/sdb': No space left on device
8108369+0 records in
8108369+0 records out
4151484416 bytes (4.2 GB, 3.9 GiB) copied, 12.3602 s 336 MB/s

The output lets us know that the write was successful, we can ignore the message saying there’s no longer any space left on ‘sdb’.

The summary also lists the amount of data copied, how long it took, and how quickly it was copied. We will look at this a bit more when I cover block size.

Example 2: Backing up a disk partition

The steps for cloning a device and backing up a partition are similar. Instead of our target file being a device, we can create an ‘.img’ (raw disk image) file.

Let’s say that our system has a separate partition for our home directory at ‘sda2’ and we want to back it up to a file named ‘home_backup.img’ in our current directory.

dd if=/dev/sda2 of=home_backup.img

It’s that easy! So now you have no excuse for not having a good backup routine.

Sure, that was easy, but there’s always more to learn.

Dealing with block size in dd command

Before we get into the next example, let’s talk about BS, or block size. If you’ve seen this used to specify a value with dd commands, you might wonder why it’s there.

If your curiosity lead you to an internet search, then I’m willing to bet that you’re probably still wondering why it’s there.

I’ll try my best to give a plain language explanation. Block devices are usually physical media with finite storage.

You can look up information on a medium like a disc by seeking a specific block of data. So for instance, the system can read a CD-ROM and search for information starting at block 500 (an arbitrary number). It can also be used to “bookend” information and maybe use info from block 500 to block 1500.

These blocks can be segmented in ways that make it efficient for the system to analyze. This may reflect the storage space of the medium, or standard system specs the medium is likely to be associated with.

I’ll continue with the example of a CD-ROM which has its own defined block size (2048). Each block must have a maximum of 2048 bytes. Even if a block only contains 100 bytes of data, it will still take up the same 2048 bytes.

There are some cases where you may want to define the block size to make dd run faster or prevent data corruption. Going back to our CD-ROM example, creating blocks of a different size could cause anomalies when it’s time for the data to be read.

If left undefined, dd will use a block size of 512. This is the smallest block size that a typical hard drive can read.

If your medium is not confined to a certain block size, you’re probably safe adjusting it for performance (write time). Let’s look at a few examples.

Performance with unspecified block size

[linuxhandbook@fedora ~]$ sudo dd if=/dev/sda of=home_backup.img
[sudo] password for linuxhandbook:
dd: writing to 'home_backup.img': No space left on device
31974953+0 records in
31974952+0 records out
16371175424 bytes (16 GB, 15 GiB) copied, 113.848 s, 144 MB/s

Performance with block size of 1024

[linuxhandbook@fedora ~]$ sudo dd if=/dev/sda of=home_backup.img bs=1024
[sudo] password for linuxhandbook:
dd: error writing 'home_backup.img': No space left on device
15987477+0 records in
15987476+0 records out
16371175424 bytes (16 GB, 15 GiB) copied, 75.4371 s, 217 MB/s

You can see that the process was performed at a faster speed. Another run with a block size of of 4096 was faster yet with a rate of 327 MB/s. System caching can also play a role in speed, but that is a topic for another day.

You may have noticed the variation in the number of records in and out. This is because we are changing the size of each block and therefore the capacity of the individual blocks, despite the output file remaining the same size. For this reason, adjusting the bs value can have unintended consequences. For example, it could lead to discrepancies when a checksum performed.

Example 3: Delete data and zero the Disk

Remember all the warnings from earlier? This command will replace every block of ‘sda’ with zeroes.

dd if=/dev/zero of=/dev/sda

How does this work? Essentially, the same as all the other in and out dd commands. What is ‘/dev/zero’?

It is a pseudo-device included on Unix/Linux operating systems that will write zeroes to a file until the it reaches the end of the file.

You can similarly use /dev/random which outputs random bits of data. This may be unnecessary if you plan to use an raw image file to replace contents since using dd will already copy unused space.

Do note that some nasty people trick unsuspecting users in running this command in various Linux forums. Now that you know what this command does, you won’t fall prey to this evil prank.

Example 4: Create .ISO from CD/DVD

You can copy directly from the cd-rom drive if your computer still has one. Earlier I mentioned that the standard byte size of a cd-rom is 2048. We’ll set the byte size to match that to avoid conversion issues and then add a couple other commands.

dd if=/dev/cdrom of=space_jam_dvd.iso bs=2048 conv=noerror,sync

Let me explain a few things. With conv=noerror, any errors will be ignored. The program will continue through to the final block without stopping. It will not stop for them.

When used in conjunction with ‘noerror’, ‘sync’ will ensure that any missing blocks of data will automatically be padded with null information.

This means the existing data will be mapped to the same locations, presumably preserving as much of the content as possible.

It’s important to make sure that your source and destination files have the same ‘bs’ set for these operations, otherwise they will not have the intended results.

Example 5: Create a bootable USB

You can use dd to create a bootable USB and it’s just as easy as you might expect. In fact, this is one of the most popular use of the dd command.

There is one extra step involved here. We use the mkfs command to build the filesystem to our USB before running ‘dd’.

Without options, it uses the default ext2 system. So assuming the USB we want to prepare is called ‘sdb’ and we want to change the file system to ext4, we would run the following command:

sudo mkfs.ext4 /dev/sdb

If you want to use with a Windows system you could replace the first part of the command with mkfs.ntfs.

You can also use the following syntax:

mkfs -t [for type] $filesystem.

Once the bootable medium is prepared, we can continue to our dd command.

dd if=someFile.iso of=/dev/sdb

Use the .iso mountable image and copy to corresponding drive name for your usb device.

Conclusion

Thanks for reading. I hope you enjoyed this primer on ‘dd’. There are so many different ways that you can use this command. I tried to cover a lot of the more useful examples. If you’ve got something you’d like to see or a direct question, I’d love to help. Let me know what you think below in the comments.
